Description

Auxiliary LED Tail Lights Kit

Adds additional LED Lights – includes 2x BR70AR2 Indicator / Tail LED Signal Lamps plus wiring harness with Deutsch connectors.

Roadvision BR70AR2 – Indicator/Tail LED Signal Lamp

Part of Roadvision’s BR70 Series, the BR70AR2 delivers Indicator and Tail light combination with LED tail light technology.  Ultra-slimline and only 28mm wide is designed for places with limited space.  Designed to be maintenance free with LED technology.  Can be mounted horizontal or vertical. Built for automotive and trailer applications, these lamps outperform conventional incandescent systems while drawing significantly less current.  Constructed with durable polycarbonate lenses and high impact ABS housings, these lamps are dust & water proof and totally maintenance free with a lifespan rated at 100,000hrs.

Functions

• Indicator / Tail

Key Features

• Ultra Slimline LED Strip
• 12V DC input with low current draw
• Brighter output than conventional incandescent systems
• 100,000 hour LED lifespan – maintenance free
• Sealed polycarbonate lens & high-impact ABS housing
• Water and dust proof
• Pre-wired with 300mm sheathed tinned copper cable
• Simple surface mount design – suits horizontal and vertical surfaces
• ADR approved (CTA Approval: CTA-060298)
• 5 Year Warranty

Specifications – BR70AR2

Function	Stop/Tail & Indicator
Input Voltage	12V DC
Number of LEDs	Indicator – 6 LEDs / Tail – 9 LEDs
Current Draw @ 13.8V	Indicator – 0.1A / Tail – 0.15A/0.05A @13.8V
Dimensions (AxBxC)	252 x 28 x 23.5mm
Mounting Hole Centres	234mm
Lens Construction	Polycarbonate
Housing Construction	High Impact ABS
Cable Length	300mm Tinned Cable
Wiring	Earth – White / Indicator – Yellow / Tail – Brown
CTA Approval	CTA-060298
Warranty	5 Years

Catalogue

Roadvision Wiring Harness to suit BR70AR2 – Sequential Indicator/Tail LED Signal Lamp

Universal driving light wiring harness to suit BR70AR2 for 2 lights. Includes Deutsch Connectors and Driving Lamper Rocker Switch.

Functions

• Wiring harness to connect BR70AR2 lights to Van
