Description
At approximately half the size of the standard small rigging pulley and weighing in at only 490g (1lb), the new Compact Rigging Pulley offers a highly impressive strength to weight ratio with an 85kN (19000lbs) MBS and a WLL of 17kN (3800lbs).
The Pulley plates are made from hot forged Aluminum and it is this manufacturing process which allows such a compact pulley to boast such great strength and dynamic load bearing capacity.
The Compact Rigging Pulley is fitted with a spring-lock closure mechanism.
Technical Data
Approved standards CE 0120
| SKU: | 8521 |
| Material: | Aluminum |
| MBS (kN/lbs): | 85kN/19,000lbs |
| WLL (kN/lbs): | 17kN/3,800lbs |
| Max Working Line Size: | 1/2″ / 13mm (38kN/8,500lbs)** |
| Topping Strop Size (MBS)*: | 5/8″ / 16mm (74kN/16,650lbs)** |
*Above figures based on using Yale Polydyne or Double Esterlon rope.
**Above figures based on using Yale Portland braid and 16mm dead eye sling.
View Datasheet
View Product Instructions
